Design and Analysis of Composite Structures for Automotive Applications: Chassis and Drivetrain

Vladimir Kobelev

ISBN: 978-1-119-51386-5 April 2019 392 Pages

E-Book
$112.99
Hardcover
$140.00
O-Book
Download Product Flyer

Download Product Flyer

Download Product Flyer is to download PDF in new tab. This is a dummy description. Download Product Flyer is to download PDF in new tab. This is a dummy description. Download Product Flyer is to download PDF in new tab. This is a dummy description. Download Product Flyer is to download PDF in new tab. This is a dummy description.

Description

A design reference for engineers developing composite components for automotive chassis, suspension, and drivetrain applications

This book provides a theoretical background for the development of elements of car suspensions. It begins with a description of the elastic-kinematics of the vehicle and closed form solutions for the vertical and lateral dynamics. It evaluates the vertical, lateral, and roll stiffness of the vehicle, and explains the necessity of the modelling of the vehicle stiffness. The composite materials for the suspension and powertrain design are discussed and their mechanical properties are provided. The book also looks at the basic principles for the design optimization using composite materials and mass reduction principles. Additionally, references and conclusions are presented in each chapter.

Design and Analysis of Composite Structures for Automotive Applications: Chassis and Drivetrain offers complete coverage of chassis components made of composite materials and covers elastokinematics and component compliances of vehicles. It looks at parts made of composite materials such as stabilizer bars, wheels, half-axes, springs, and semi-trail axles. The book also provides information on leaf spring assembly for motor vehicles and motor vehicle springs comprising composite materials.

  • Covers the basic principles for the design optimization using composite materials and mass reduction principles
  • Evaluates the vertical, lateral, and roll stiffness of the vehicle, and explains the modelling of the vehicle stiffness
  • Discusses the composite materials for the suspension and powertrain design
  • Features closed form solutions of problems for car dynamics explained in details and illustrated pictorially

Design and Analysis of Composite Structures for Automotive Applications: Chassis and Drivetrain is recommended primarily for engineers dealing with suspension design and development, and those who graduated from automotive or mechanical engineering courses in technical high school, or in other higher engineering schools.
