Microwave and radio frequency (RF) elements play an important role in communication systems, and, due to the proliferation of radar, satellite and mobile wireless systems, there is a need for the study of electromagnetism.
Each of the nine chapters of this book provides a complete analysis and modeling of the microwave structure used for emission or reception technology, providing students with a set of approaches that can be used for current and future RF and microwave circuit designs. The authors emphasize the practical nature of the subject by summarizing the analysis steps and giving numerous examples of problems and exercises complete with solutions, making this book theoretical, but also experimental, with over 16 microwave problems. This approach has produced a coherent and practical treatment of the subject.
The book has grown out of the authors’ own teaching and, as such, has a unity of methodology and style. It provides basic knowledge of microwave and RF range and is intended for microwave engineers and for advanced graduate students.
PART 1. TRANSMISSION LINES 1
CHAPTER 1. ELECTROMAGNETIC OF TEM TRANSMISSION LINES 3
CHAPTER 2. LOSSES IN TEM TRANSMISSION LINES 23
CHAPTER 3. DETERMINATION OF THE CHARACTERISTICS OF TEM LINES 51
PART 2. GUIDES 77
CHAPTER 4. ELECTROMAGNETIC IN LINEAR, HOMOGENEOUS, ISOTROPIC AND LOSSLESS GUIDES 79
CHAPTER 5. LOSSES IN GUIDES 107
CHAPTER 6. RECTANGULAR TM AND TE GUIDES 123
CHAPTER 7. CIRCULAR TM AND TE GUIDES 151
PART 3. CAVITIES 173
CHAPTER 8. RECTANGULAR TE011 CAVITY 175
CHAPTER 9. CIRCULAR TEmnp AND TMmnp CAVITIES 191
